Saturday, 29 April 2017

Application Of Kusam Meco Digital Multimeter 405MK-1 ...

Brand : Kusam Meco
Model
: 405MK-1

About Kusam Meco :
In the eighties, use of Digital Test & measuring Instruments were in a nascent stage. At that time 90 % of the multi meters & clampmeters used in the industry were Analog meters.

Kusam-Meco introduced & Pioneered the use of Digital Multimeters & clampmeters in the Indian industry. Kusam-Meco continues to introduce new products with unique features & protection to meet current market demand & safety to cater customers diverse applications. The promoters of the company have thire 40 years of experience in the field

Kusam-Meco has a proven track record of offering products that have surpassed industry standard certification such as UL,CE, ISO 9001:2008. Quality Assurance certification. their quality, Reproduction, Service & Credibility has endowed on their the praise of their peers in the Test & Measuring Instrument Industry. The company has testing facilities traceable to NPL standards to provide good quality instruments to the customers.

Kusam Meco's commitment to their customers is their priority which is backed by a network of dealers & distributors to provide prompt service to that customers which
reflect this commitment.

Kusam Meco is ISO 9001:2008 certified since March 2005, for sales & Service of their product range. their products are patronized by all government Laboratories, different segments of the industry, Engineering colleges, Research laboratories.

They are dedicated to provide the most advanced control & instrumentation products in the world. Today, Kusam-Meco has a unique position in India as the leading company in the field of measurement & control. They anticipate the needs of the times & provide the best solutions to their customers.

Product Range :
Measuring Instruments, Power Clamp Meters, Thermo Hygrometers, Earth Resistance Testers, Insulation Resistance Testers, Digital Multi Meters, Milli Ohm Meter, Digital Clamp Meters, Tachometer,ELCB Testers, Laboratory Instruments, Oscilloscopes, Gas Analysers Calibrator, Lux meters, Banking Solutions, LCR Meters

Product Description :
A multimeter is an electronic measuring instrument that combines several measurement functions in one unit. A typical multimeter can measure voltage, current, and resistance. Analog multimeters use a microammeter with a moving pointer to display readings. Digital multimeters (DMM, DVOM) have a numeric display, and may also show a graphical bar representing the measured value. Digital multimeters are now far more common due to their cost and precision, but analog multimeters are still preferable in some cases, for example when monitoring a rapidly varying value.

Applications :
A multimeter can be a hand-held device useful for basic fault finding and field service work, or a bench instrument which can measure to a very high degree of accuracy. They can be used to troubleshoot electrical problems in a wide array of industrial and household devices such as electronic equipment, motor controls, domestic appliances, power supplies, and wiring systems.

Features:
Auto Polarity Display.
Overrange Indication.
Low Battery Indication.
Data Hold Function.
Auto power off
Shock Resistant & Fire Retardant Casing.
Input warning beeper
Logic test, Diode Test & Continuity Test
Duty Cycle Function.
CE approved

General Specification :
Sensing : True RMS Sensing.
Basic Accuracy : ±(0.05%rdg + 3 dgts)
Display : 4½ digits, 19999 counts large LCD display with function and unit sign annunciators.
Display Size : 17 mm
Over range indication : “1” most significant digit blinks.
Low battery indication : The “ ” is displayed when the battery voltage drops below the operating level.
Polarity : Automatic, (-) negative polarity indication.
Auto power off : Meter automatically shuts down after approx.45 minutes of inactivity.
Altitude : 6561.7 (2000M)
Measurement rate : 2.5 times per second, nominal
Operating Temperature : 0°C to 50°C at < 70% R.H.
Storage Temperature : -20°C to 60°C, 0 to 80 % R.H with battery removed from meter.
Temperature Coefficient : 0.1 x (specified accuracy) / °C (0°C ~ 18° or 28°C ~ 50°C)
Power : Single 9V Alkaline battery.
Battery life : 500 hours typical with alkaline.
Dimension : 198(H) x 90(W) x 44(D)mm.
Weight : Approx. 400g including battery.

Accessories :
Test leads pair, User’s Manual, Battery installed, Carrying Case.

For more information,please visit our online business portal : www.autocon.biz



How To Use Kusam Meco Digital Multimeter 207-MK-1(T) ???

Brand :  Kusam Meco
Model : 207-MK-1(T)

About Kusam Meco
:
In the eighties, use of Digital Test & measuring Instruments were in a nascent stage. At that time 90 % of the multi meters & clamometers used in the industry were Analog meters.

Kusam-Meco introduced & Pioneered the use of Digital Multimeters & clampmeters in the Indian industry. Kusam-Meco continues to introduce new products with unique features & protection to meet current market demand & safety to cater customers diverse applications. The promoters of the company have thire 40 years of experience in the field

Kusam-Meco has a proven track record of offering products that have surpassed industry standard certification such as UL,CE, ISO 9001:2008. Quality Assurance certification. their quality, Reproduction, Service & Credibility has endowed on their the praise of their peers in the Test & Measuring Instrument Industry. The company has testing facilities traceable to NPL standards to provide good quality instruments to the customers.

Kusam Meco's commitment to their customers is their priority which is backed by a network of dealers & distributors to provide prompt service to that customers which
reflect this commitment.

Kusam Meco is ISO 9001:2008 certified since March 2005, for sales & Service of their product range. their products are patronized by all government Laboratories, different segments of the industry, Engineering colleges, Research laboratories.

They are dedicated to provide the most advanced control & instrumentation products in the world. Today, Kusam-Meco has a unique position in India as the leading company in the field of measurement & control. They anticipate the needs of the times & provide the best solutions to their customers.

Product Range :
Measuring Instruments, Power Clamp Meters, Thermo Hygrometers, Earth Resistance Testers, Insulation Resistance Testers, Digital Multi Meters, Milli Ohm Meter, Digital Clamp Meters, Tachometer,ELCB Testers, Laboratory Instruments, Oscilloscopes, Gas Analysers Calibrator, Lux meters, Banking Solutions, LCR Meters

Product Description
:
A multimeter is an electronic measuring instrument that combines several measurement functions in one unit. A typical multimeter can measure voltage, current, and resistance. Analog multimeters use a microammeter with a moving pointer to display readings. Digital multimeters (DMM, DVOM) have a numeric display, and may also show a graphical bar representing the measured value. Digital multimeters are now far more common due to their cost and precision, but analog multimeters are still preferable in some cases, for example when monitoring a rapidly varying value.

Applications
:
A multimeter can be a hand-held device useful for basic fault finding and field service work, or a bench instrument which can measure to a very high degree of accuracy. They can be used to troubleshoot electrical problems in a wide array of industrial and household devices such as electronic equipment, motor controls, domestic appliances, power supplies, and wiring systems.

Features:
High Accurancy Reading.
Large LCD For Easy Reading.
Diode & Continuity Test
Overload Protection On All Ranges.
Data-Hold, Facility
Duty Cycle Test

General  Specification :

Display:3 digit LCD. Maximumreading 3999 withautomatic sign andfunction annunciators.
Overrange :Highest digit of (1) or (-1)indicationis displayed.
Low battery :The “         ” sign is displayedwhen the battery voltage dropsbelow the operating Voltage.
Measurement : 2.5 measurements rateper Second, nominal.
Operating :0°C to + 50°C, <70% RH. temperature
Storage :-20°C to 60°C, <80% RHtemperaturewith battery removed.
Accuracy:Accuracy specifications at23 ± 5°C less than 75% RH.
Power : Single 9 V Battery
Dimension:151mm (L),70mm(W),38mm(H
Weight:Approx (210 grams)including battery
Alarm:Buzzer Sounds when thelead is connected to thewrong input terminals.

Accessories:

Test leads,Operators Manual, Battery, Carrying Case,  Protective Holster, Temperature Probe

For more information,please visit our online business portal : www.autocon.biz





How to measure total flow of material by Multispan Flow Indicator Cum Totalizer MFC-3006 ?

Brand  : Multispan
Model  : MFC-3006

About Multispan
:
With a modest beginning in 1986 in 1200 sq ft workshop area, “Multispan Instruments Company” was founded on the principles of providing user-friendly & “frugal” innovation based panel mounted Temperature controllers for injection moulding, extrusion units and other plastic processing machinery manufacturers in India. In period, 1990-1995 company widened its product offerings like Digital timers & counters which complimented Temperature controller in control panels.

During 1995-2000, with more than 50 products, the company R&D efforts transitioned these products to micro-controller based design from solid-state based technology. In the same period, the company setup area was totaling around 3500 sq ft area. In 2003, PID based technology was introduced in Temperature controlling behavior based on practical industrial tests carried out for various indigenously manufactured machine types suitable as per Indian industrial atmosphere. With 100+ products, Multispan products were now used across industrial machines countrywide. Factory & office was expanded to more than 10000 sq ft area.

By 2005, a varied range of temperature controller models based on PID behavior was launched suited for each Indian manufactured machine type with different price points. By 2010, with product portfolio reaching around 200 models, sensitive industrial applications were also covered with high-featured products that include Multi-channel temperature scanners, Sequence timers, Multi-parameter energy meters along with an option of computer & printer connectivity. In April 2013, a new 25000 sq ft production facility was inaugurated to satisfy the growing production targets as per market demands.

Product Range :
Process Control Instruments, Temperature Controllers-PID, Power &  Energy Meters, Programmable Timers, Programmable Counter,  Protection Devices & Relays, Thyristor DC Drive

Product Description :
Features :

0-10vdc / 4-20ma / 0-20ma / pulse input factory setting
6 digit total flow, analog input or pulse input, programmable range

Specifications :
Display : 7 segment, 6 digit, 0.4”, RED LED display- Total Flow
Input    : 4-20 mA DC / 0-10V DC / Pulse (Factory Set)
Enclosure Material : Metal
Size     : 48 X 96 X 120 mm

For more information, please visit our Online Business Portal :  www.autocon.biz

Friday, 28 April 2017

How Multispan Flow Indicator Cum Totaliser MFC-1048 can measure flow of material ???

Brand  : Multispan
Model : MFC-1048

About Multispan :
With a modest beginning in 1986 in 1200 sq ft workshop area, “Multispan Instruments Company” was founded on the principles of providing user-friendly & “frugal” innovation based panel mounted Temperature controllers for injection moulding, extrusion units and other plastic processing machinery manufacturers in India. In period, 1990-1995 company widened its product offerings like Digital timers & counters which complimented Temperature controller in control panels.

During 1995-2000, with more than 50 products, the company R&D efforts transitioned these products to micro-controller based design from solid-state based technology. In the same period, the company setup area was totaling around 3500 sq ft area. In 2003, PID based technology was introduced in Temperature controlling behavior based on practical industrial tests carried out for various indigenously manufactured machine types suitable as per Indian industrial atmosphere. With 100+ products, Multispan products were now used across industrial machines countrywide. Factory & office was expanded to more than 10000 sq ft area.

By 2005, a varied range of temperature controller models based on PID behavior was launched suited for each Indian manufactured machine type with different price points. By 2010, with product portfolio reaching around 200 models, sensitive industrial applications were also covered with high-featured products that include Multi-channel temperature scanners, Sequence timers, Multi-parameter energy meters along with an option of computer & printer connectivity. In April 2013, a new 25000 sq ft production facility was inaugurated to satisfy the growing production targets as per market demands.

Product Range :
Process Control Instruments, Temperature Controllers  -PID, Power &  Energy Meters, Programmable Timers, Programmable Counter,  Protection Devices & Relays, Thyristor DC Drive

Product Description
:

Features
⇰ Micro controller based Digital Flow cum Totalizer Indicator
⇰ Seven Segment Brighter Display
⇰ Programmable by Front Key
⇰ RS-485 MOD BUS Facility /Facility for HMI & PLC.
⇰ RS-232 Serial Communication available for Printer & PC Interfacing.

Specifications
:
8 Digit Total Flow + 4Digit Flow Rate Display, Analog input or pulse Input, Programmable Range
Input: 0-10VDC / 4-20mA / 0-20mA / Pulse Input (Factory Setting)
Enclosure Material : Plastic
Size : 96 X 96 X 100 mm

For more information, please visit our Online Business Portal :  www.autocon.biz


How Multispan Fault Annunciator FA-11 can display fault in operation ???

Brand  : Multispan
Model  : FA-11

About Multispan
:
With a modest beginning in 1986 in 1200 sq ft workshop area, “Multispan Instruments Company” was founded on the principles of providing user-friendly & “frugal” innovation based panel mounted Temperature controllers for injection moulding, extrusion units and other plastic processing machinery manufacturers in India. In period, 1990-1995 company widened its product offerings like Digital timers & counters which complimented Temperature controller in control panels.

During 1995-2000, with more than 50 products, the company R&D efforts transitioned these products to micro-controller based design from solid-state based technology. In the same period, the company setup area was totaling around 3500 sq ft area. In 2003, PID based technology was introduced in Temperature controlling behavior based on practical industrial tests carried out for various indigenously manufactured machine types suitable as per Indian industrial atmosphere. With 100+ products, Multispan products were now used across industrial machines countrywide. Factory & office was expanded to more than 10000 sq ft area.

By 2005, a varied range of temperature controller models based on PID behavior was launched suited for each Indian manufactured machine type with different price points. By 2010, with product portfolio reaching around 200 models, sensitive industrial applications were also covered with high-featured products that include Multi-channel temperature scanners, Sequence timers, Multi-parameter energy meters along with an option of computer & printer connectivity. In April 2013, a new 25000 sq ft production facility was inaugurated to satisfy the growing production targets as per market demands.

Product Range :
Process Control Instruments, Temperature Controllers -PID, Power &  Energy Meters, Programmable Timers, Programmable Counter,  Protection Devices & Relays, Thyristor DC Drive

Product Description :
Features
:

Micro controller Based Fault Annunciator
16x2 Brighter LCD Display
LED Indication for Alarm & Machine Trip Output
Fault Defined by User with Software
Programmable by Front Key
Compact Size

Descriptions :
Fault Annunciator FA-11
Display : 16 Character by 2 line with GREEN Light LCD display
Input Signal : 10 Input Potential Free Contact

OUTPUT :
Control output : 3-Relay
Relay Ratings : 2 (NO-C) Contact for Audio and Visual Alarm, 1 C/O for Machine Trip

SPECIFICATION :
Power Supply : 90 - 270V AC / DC, 50 / 60 Hz, SMPS
Indication : 1) Audio alarm 2) Visual alarm 3) Machine output
Enclosure Material : Plastic
Operating Ambient Temp
: 0°C - 55°C
Relative Humidity
: Up to 95% RH Non Condensing
Operating Ambient Temp : 0ºC - 55ºC
Relative Humidity : Up to 95% RH Non Condensing
Size (H x W X D) :96x96x50 mm

For more information, please visit our Online Business Portal : www.autocon.biz

How Multispan Digital Time Totalizer DTT-5000 can measure time ???

Brand  : Multispan
Model : DTT-5000

About Multispan :
With a modest beginning in 1986 in 1200 sq ft workshop area, “Multispan Instruments Company” was founded on the principles of providing user-friendly & “frugal” innovation based panel mounted Temperature controllers for injection moulding, extrusion units and other plastic processing machinery manufacturers in India. In period, 1990-1995 company widened its product offerings like Digital timers & counters which complimented Temperature controller in control panels.

During 1995-2000, with more than 50 products, the company R&D efforts transitioned these products to micro-controller based design from solid-state based technology. In the same period, the company setup area was totaling around 3500 sq ft area. In 2003, PID based technology was introduced in Temperature controlling behavior based on practical industrial tests carried out for various indigenously manufactured machine types suitable as per Indian industrial atmosphere. With 100+ products, Multispan products were now used across industrial machines countrywide. Factory & office was expanded to more than 10000 sq ft area.

By 2005, a varied range of temperature controller models based on PID behavior was launched suited for each Indian manufactured machine type with different price points. By 2010, with product portfolio reaching around 200 models, sensitive industrial applications were also covered with high-featured products that include Multi-channel temperature scanners, Sequence timers, Multi-parameter energy meters along with an option of computer & printer connectivity. In April 2013, a new 25000 sq ft production facility was inaugurated to satisfy the growing production targets as per market demands.

Product Range :
Process Control Instruments, Temperature Controller -PID, Power &  Energy Meters, Programmable Timers, Programmable Counter,  Protection Devices & Relays, Thyristor DC Drive

Product Description :
Features

• Micro controller based Digital Time Totalizer
• Reset by Front Keypad
• Back Reset also available on customer request
• Available in IVORY colour also

Descriptions :
Digital Time Totalizer DTT-5000,
Display : 7 segment, 6 digit, 0.4”, RED LED display.
Time Setting Range : 99.59.59 hrs/min/sec, 9999.59 hr/min, 9999.59 min/sec, 999999 hr, 999999 min, 999999 sec (configurable) .
INPUT :
Start Pulse : Micro switch / Limit switch / Proximity Switch / 230V AC(Factory Set)
Start Pulse Type : Power ON / Enable / Trigger (Factory Set)

SPECIFICATION :
Reset Facility : By Front Keypad
Memory Retention : Non-Volatile Memory
Power Supply : 230V AC ±10%, 50 Hz (Linear Power Supply)
Enclosure Material : Plastic
Operating Ambient Temp : 0ºC - 55ºC
Relative Humidity
: Up to 95% RH Non Condensing
Size (H x W X D) : 36x72x75 mm


For more information, please visit our Online Business Portal :  www.autocon.biz

How to measure temperature using Multispan Digital Temperature Indicator TI-41 ???

Brand  : Multispan
Model : TI-41

About Multispan :
With a modest beginning in 1986 in 1200 sq ft workshop area, “Multispan Instruments Company” was founded on the principles of providing user-friendly & “frugal” innovation based panel mounted Temperature controllers for injection moulding, extrusion units and other plastic processing machinery manufacturers in India. In period, 1990-1995 company widened its product offerings like Digital timers & counters which complimented Temperature controller in control panels.

During 1995-2000, with more than 50 products, the company R&D efforts transitioned these products to micro-controller based design from solid-state based technology. In the same period, the company setup area was totaling around 3500 sq ft area. In 2003, PID based technology was introduced in Temperature controlling behavior based on practical industrial tests carried out for various indigenously manufactured machine types suitable as per Indian industrial atmosphere. With 100+ products, Multispan products were now used across industrial machines countrywide. Factory & office was expanded to more than 10000 sq ft area.

By 2005, a varied range of temperature controller models based on PID behavior was launched suited for each Indian manufactured machine type with different price points. By 2010, with product portfolio reaching around 200 models, sensitive industrial applications were also covered with high-featured products that include Multi-channel temperature scanners, Sequence timers, Multi-parameter energy meters along with an option of computer & printer connectivity. In April 2013, a new 25000 sq ft production facility was inaugurated to satisfy the growing production targets as per market demands.

Product Range :
Process Control Instruments, Temperature Controllers -PID, Power &  Energy Meters, Programmable Timers, Programmable Counter,  Protection Devices & Relays, Thyristor  DC Drive

Product Description :
Features:

⇾ Micro controller based Digital Temperature Indicator
⇾ Seven Segment Brighter LED Display
⇾ Compact size available
⇾ Easy to use

Descriptions :
Display : 7 segment, 4 digit, 0.4”, RED LED display.
INPUT  :
Sensor : J / K / PT-100 2W/3W (Factory Set)
Range  : J (0ºC to 400ºC OR 0ºC to 600ºC), K(0ºC to 1200ºC), PT-100 2W/3W(- 50.0ºC to 200.0ºC, 0ºC to 400ºC)

SPECIFICATION :
Resolution
: J , K 1ºC, PT-100 2W/3W 1ºC, 0.1ºC
Accuracy       : ±1% of  FSD
Power Supply
: 90 - 270V AC/DC, 50/60Hz, SMPS
Indication      : “OPEN” message is displayed if sensor is disconnected
Enclosure Material : Plastic
Operating Ambient Temp : 0ºC - 55ºC
Relative Humidity : Up to 95% RH Non Condensing
Size (H x W X D)   : 48x48x70 mm

For more information, please visit our Online Business Portal : www.autocon.biz
